Slotted channel for heavy-duty drainage Lamina Magna
- reinforced channel body including slotted attachment
- subtle yet highly resilient dewatering for heavy-duty use
- coordinated flush and inspection boxes available
- individual slot widths, drain bodies, end pieces and connectors produced on request
Available in shop
Standard sizes available in 2 to 3 business days
Special sizes available in 5 to 15 business days
Our Lamina Magna slotted drainage channel for heavy-duty use really is the perfect solution for successful linear drainage. When installed on courtyard surfaces, in public spaces or on driveways, for example, only a discreet inlet slot is visible on the surface. Thanks to the generously proportioned, enclosed channel body, which transports the accumulating water to the drainage points as quickly as possible, the linear drainage system is capable of diverting even large quantities of precipitation in just a short space of time. Professionally encased in concrete, the Lamina Magna can even withstand the loads of moving vehicles. We produce the heavy-duty slotted drainage channel in hot-dip galvanised steel or stainless steel with a length of 1,000mm and a thickness of either 3mm or 4mm. Individual slot widths can be manufactured on request, as can individual drain bodies, end pieces and connectors. Our flush and inspection boxes fit the channel perfectly and are essential for the regular maintenance and cleaning of the slotted channel.
Slotted channel for heavy-duty drainage Lamina Magna |
|
|---|---|
|
Inlet width |
100 mm 150 mm |
|
Lengths |
1.000 mm |
|
Neck height / total height |
160 mm / 260 mm 160 mm / 310 mm |
|
Material |
Stainless steel (V2A) 4.0 mm Stainless steel (V2A) 3.0 mm Hot-dip galvanised steel 4.0 mm hot-dip galvanised steel 3.0 mm |
|
Infos |
Individual dimensions possible |
|
Accessories |
End pieces Connectors Inspection boxes |
Slotted channel for heavy-duty drainage Lamina Magna
