Shower-channel wedge profiles
High-quality stainless-steel profiles for gradient compensation with optional glass groove
- Versatile variants for floor-level shower areas
- Stainless-steel wedge profiles for gradient compensation
- Sloping edge and perforated supporting bases for tiling
- Variants with integrated glass groove available for thicknesses up to 12mm
- Profile sets for anchoring glass panels in the wall and floor area
- Matching end profiles for a uniform, all-round stainless-steel look
Any questions? We are happy to help personally!
+49 5207/9504-5241 request@richard-brink.com
Walk-in shower areas that guide the water towards the shower channel over a sloping screed as opposed to having a shower tray combine a minimalistic aesthetic with maximum comfort. Nowadays accessible, walk-in showers are a firm feature of modern bathroom design. Our new stainless-steel shower-channel wedge profiles are available now and afford a whole host of new visual accents and other functional benefits.
Our range of bathroom systems encompasses multiple variants of our stainless-steel profiles for floor-level shower areas. The basic choice is between versions for gradient compensation or the same with an additional groove for glass panels. On top of that we also offer wall-side end profiles in the floor zone as well as supplementary products for mounting a glass panel by the wall.
Profiles for gradient compensation
Our stainless-steel gradient wedges create an attractive and also reinforced transition between the built-up sloping screed and the surrounding horizontal tiled surface. The wedge profiles with a gradient of 2% are available in lengths of 980mm, 1,480mm and 1,980mm. As well as the sloping edge on the sides, the profiles also have perforated supporting bases for tiling.
Profiles with glass groove
If the plan is to install glass panels in the shower area as well as compensating for the gradient, this can be done using our profiles with integrated glass groove. These variants, also made from stainless steel, are available in lengths of 980mm or 1,480mm with a gradient of 2%. The profiles are designed to hold glass panels with a maximum thickness of 12mm securely in place. If glass elements need to be fitted around corners by the wall, our range also includes special versions that come as a full set along with the accompanying floor profiles, enabling the glass panels to be securely anchored both horizontally and vertically.
End profiles for a uniform look
We also manufacture matching end profiles for the front side of the wall areas to complement our gradient wedge profiles. These create a uniform, all-round stainless-steel look thanks to the direct connection of the end profiles with the gradient wedges. We manufacture these product solutions in a length of 1,480mm and for tile thicknesses of 10mm or 20mm. Here, too, we supply a complete set consisting of gradient wedges and end profiles.
Shower channel wedge profiles for slope compensationtoujours à gauche et à droite |
|
|---|---|
Materials |
Stainless steel (V2A), polished |
Material thickness |
1,0 mm |
Gradient |
2 % |
Lengths |
980 mm 1.480 mm 1.980 mm |
Edge sequences end face 1 |
40 x 28 x 8 mm 40 x 38 x 8 mm 40 x 48 x 8 mm |
Edge sequence end face 2 |
40 x 8 x 8 mm |
Details |
incl. row of holes in the support leg |
Shower channel wedge profiles with glass holderalways left and right |
|
|---|---|
Materials |
Stainless steel (V2A), polished |
Material thickness |
1,0 mm |
Gradient |
2 % |
Lengths |
980 mm 1.480 mm |
Widths |
13 mm |
Maximum glass thickness |
12 mm |
Edge sequence end face 1 |
50 x 20 x 25 mm |
Edge sequences end face 2 |
50 x 20 x 45 mm 50 x 20 x 55 mm |
Details |
Inclined wedge is built in two parts |
Shower channel wedge profiles for holding glass on the wall |
|
|---|---|
Materials |
Stainless steel (V2A), polished |
Material thickness |
1,0 mm |
Maximum glass thickness |
12 mm |
Lengths |
1.980 mm |
Widths |
13 mm |
Edge sequence end face |
50 x 20 x 20 mm |
Details |
Profile is built in two parts |
End profiles |
|
|---|---|
Materials |
Stainless steel (V2A), polished |
Material thickness |
1,0 mm |
Heights |
35 mm 45 mm |
Lengths |
1.480 mm |
Edge sequences front side |
40 x 20 x 35/45 mm |
