Polymer concrete channel Poly-Fortis
Lightweight for heavy duty conditions
- ideal for linear drainage under heavy-duty conditions
- high-quality resin admixture in the material
- lower weight than standard channels
- excellent resilience to a variety of chemicals
- cassette-shaped moulded sections to anchor into concrete foundation
- polymer drainage units, channel sections with attached nozzle and end pieces available
- large selection of compatible heavy-duty gratings
- Prisma or Zippa cast gratings for use with cast frame
Any questions? We are happy to help personally!
+49 5207/9504-5241 request@richard-brink.com Order now
Our polymer concrete channels “Poly-Fortis” offer an impressive range of benefits, making them a sturdy, reliable drainage solution that will last for years to come. The new polymer concrete formula ensures very high water impermeability. The concrete channels themselves absorb hardly any water thanks to high-quality resins mixed with quartz sand. And rubber seals at the channel joints mean that even transitions between individual elements do not let water through, ensuring excellent redirection of collected precipitation.
Compared to standard concrete designs, the “Poly-Fortis” weighs significantly less – but customers and project managers don’t have to worry about the material being flimsy. Quite the opposite: as lightweight as they are, these channels offer great resilience, right up to class D 400. The material mix also makes it possible to achieve large cross-sections for maximum flow and thin channel wall thicknesses. The channels are also extremely resistant to chemicals: the plastic component of their make-up is primarily responsible for this, as it shields and effectively protects the main mineral components of the channels.
In addition to the longitudinal bar and mesh gratings for heavy-duty use, we are offering high-quality cast gratings in different designs. The “Zippa” and “Prisma” designs can easily handle heavy loads of over 40 tons – the “Zippa” grating even meets the requirements for load class E 600. The high resilience of the gratings is determined not only by the premium casting alloy used to make them but also their sophisticated shape, which lends these products a high-quality aesthetic. The look is enhanced further with a premium CDP coating.
Concrete channel Poly-Fortis |
|
|---|---|
|
Widths (nominal size) |
155 mm (DN 100) 206 mm (DN 150)* 257 mm (DN 200) ** *DN 150 only available in height 200 and 250 mm available **DN 200 only available in height 300 mm for hot-dip galvanized steel frames for cast iron gratings, cast iron frames for cast iron gratings and stainless steel frames |
|
Load class: |
D 400 E 600 (depending on the height used) |
|
Lengths |
500 mm 1.000 mm |
|
Heights |
150 mm 175 mm 200 mm* 250 mm* 300 mm** *DN 150 only available in height 200 and 250 mm available **DN 200 only available in height 300 mm for hot-dip galvanized steel frames for cast iron gratings, cast iron frames for cast iron gratings and stainless steel frames |
|
Material |
Polymer concrete |
|
Frames depending on grate support optionally made of: |
hot-dip galvanised steel stainless steel cast iron |
|
Accessories |
End pieces Sink boxes incl. dirt trap made of V2A Gutters with integrated connection pieces |
